Dipmeter Solinst 201

With the integrated temperature measurement, it is possible to measure a temperature profile in addition to measuring the water level. With this key parameter, you are equipped for the future requirements of environmental measurement technology. The water temperature is displayed on the LCD of the cable drum and covers a measuring range from -20°C to +125°C.

Water temperature and environment

Groundwater temperature has a direct impact on the biological activity of plants and animals. Furthermore, it is an important parameter for the water quality as well as the chemical composition.
Water temperature is a key parameter affecting various physical, chemical and microbial processes. Especially the solubility of gases and the groundwater organisms show a sensitive dependence on the temperature in the water.

Trends in groundwater temperature, Federal Environment Agency, Vienna 2011.

This important environmental parameter can be measured uncomplicatedly and reliably with this light plummet

Durable stainless steel measuring probe

The probe is made of stainless steel and is waterproof up to 300m. The measuring point is placed close to the probe tip to minimize water displacement during the measuring process.
The temperature sensor is integrated in the tip of the probe and provides accurate measurement results from -20°C to 125°C. The probe as a whole acts as a heat sink, which is why it should be completely submerged in water for more accurate measurement results. The connection between the tape measure and the probe is designed for easy changeover to replace the probe one at a time should this become necessary.

Fields of application for the dipmeter

• Temperature profiles at groundwater monitoring sites, boreholes, shafts and open waters
• Detection of outflows, inflows or other sources of thermal stress on the water
• Early warning of changes in water quality, oxygen saturation, and conductivity
• Monitoring and prediction of changes in the water balance
• Geothermal drilling and investigations
